Cyclone IV EP4CE10F17C8N FPGA development board Learning Board core-board

100 % of buyers enjoyed this product! 0 orders
List price:
US $62.80
Price:
US $56.52

Product Description

  • Using original FT232RL
  • Support Windows 8
  • Support 3 kinds of power supply mode: 5V external power supply; 3.3V external power supply; by the external power supply (requires 3.3V-5V)
  • With 3 LED RXD, LED POWER, LED LED:TXD
  • TXD, RXD, RTS#, CTS#: the bent pin out
  • Reserve the rest function PIN: bonding pad (distribution row needle, row of seats, can be inserted or the access to the user’s system; support insert PIN spacing of board)

Cyclone IV EP4CE10F17C8N FPGA development board Learning Board core-board

    [core interface]

  1. Core board slot
    Easy access to the core board.
    Such as: CoreEP2C8 / CoreEP4CE10 / Core3S500E and so on.
  2. 8 I/Os_1 interface
    Convenient access to all kinds of modules.
  3. 8 I/Os_2 interface
    Easy access to various types of modules.
  4. 16 I/Os_1 interface
    Easy access to various types of modules.
  5. 16I/Os_2 interface
    Easy access to various types of modules.
  6. 32 I/Os_1 interface
    Easy access to various types of modules.
  7. 32I/Os_2 interface
    Easy access to various types of modules.
  8. 32I/Os_3 interface
    Easy access to various types of modules.
    The above interface:

  • Can be simulated: USART, I2C, SPI, PS/2 and other interfaces
  • Driver: FRAM, FLASH, USB, Ethernet, etc
  1. SDRAM interface
    Convenient access to the SDRAM module.
    Can be used as the MCU pin.
  2. lcd interface
    Can access LCD12864, LCD22, LCD1602.
  3. 1-WIRE interface
    Easy access to various types of use 1-WIRE interface devices (TO-92 package).
    Such as temperature sensor DS18B20, electronic registration code DS2401 module and so on.
    [other interface]

  1. 5 v DC interface

    [device profile]

  2. rocker
    Up, down, left, right, press, a total of 5 states.
  3. Buzzer
  4. potentiometer
    For LCD22 backlight adjustment, or LCD12864 and LCD1602 contrast adjustment
  5. Power switch

    [jump line show]

  6. Buzzer jumper
  7. Jumper 1-WIRE
  8. Five rocker jumper
    Jump line above instructions:
    Short Jumper: access to the specified I/O sample program;
    Disconnect Jumper: can be modified to use a custom I/O. connection line accessConvenient connection with peripherals.

Core board resources

    [chip]

  1. EP4CE10F17C8N
    Following is EP4CE10F17C8NCore resource parameters:
    Operating frequency: 50MHz;
    Operating voltage: 1.15 V ~ 3.465 V.
    Loading: BGA256; The I/O port: 164;
    Les:10K;RAM:414kb;
    PLLs:2;
    Can be realized through the JTAG interface debugging download: download.
  2. AMS1117-3.3 (PCB) on the back
    3.3 V voltage regulator.
  3. AMS1117-2.5 (PCB back)
    1.2 V voltage regulator.
  4. AMS1117-1.2 (PCB) on the back
    1.2V voltage stabilizing device.
  5. EPCS16
    Serial FLASH memory, used to store the code.
    [other device profiles]

  1. Power LED
  2. The user of LED
  3. Reset button
  4. NCONFIG buttons
    FPGA chip can be re configured, equivalent to restart the power supply
  5. 50M active crystal
    [interface]
  6. JTAG interface
    Support download and debug.
  7. FPGA pin interface
    Lead to VCC, GND and all I/O

Shipping list:

  1. OpenEP4CE10-C development board x1
  2. 4 pin connecting x2 experiment
  3. 2 pin cable x2 experiment
  4. Take the USB wire x1
  5. Software CD x1
